자동화 재무 문서 처리
고급
이것은Content Creation, Multimodal AI분야의자동화 워크플로우로, 76개의 노드를 포함합니다.주로 Set, Code, Merge, SplitOut, GoogleDrive 등의 노드를 사용하며. Google Gemini OCR를 사용한 자동 재정 문서 처리
사전 요구사항
- •Google Drive API 인증 정보
- •대상 API의 인증 정보가 필요할 수 있음
- •Google Sheets API 인증 정보
사용된 노드 (76)
워크플로우 미리보기
노드 연결 관계를 시각적으로 표시하며, 확대/축소 및 이동을 지원합니다
워크플로우 내보내기
다음 JSON 구성을 복사하여 n8n에 가져오면 이 워크플로우를 사용할 수 있습니다
{
"meta": {
"instanceId": "37f50031da2d48584a7239d61fbf5ae3e1b2415708520d9af5429cf2a73a8c3d",
"templateCredsSetupCompleted": true
},
"nodes": [
{
"id": "ec55993a-2652-4e2d-9e25-3e507f93c487",
"name": "채팅 메시지 수신 시",
"type": "@n8n/n8n-nodes-langchain.chatTrigger",
"position": [
-560,
912
],
"webhookId": "9915b6a2-5823-45b1-9b42-95f428906e87",
"parameters": {
"options": {
"allowFileUploads": true,
"allowedFilesMimeTypes": "*"
}
},
"typeVersion": 1.1
},
{
"id": "ce9ddc97-8776-4805-9299-e8898ccd4cdc",
"name": "분할",
"type": "n8n-nodes-base.splitOut",
"position": [
128,
1120
],
"parameters": {
"options": {},
"fieldToSplitOut": "parsedData['Line Items']"
},
"typeVersion": 1
},
{
"id": "a4788bf0-20d2-4e21-9e68-37202475cdcd",
"name": "스티커 노트1",
"type": "n8n-nodes-base.stickyNote",
"position": [
-976,
912
],
"parameters": {
"width": 340,
"height": 420,
"content": "# Mark - Accountant\n\n\n\n"
},
"typeVersion": 1
},
{
"id": "25cc249b-c780-4a34-8cbb-b2aa8a8adf54",
"name": "확인",
"type": "n8n-nodes-base.set",
"position": [
768,
912
],
"parameters": {
"options": {},
"assignments": {
"assignments": [
{
"id": "de0be0e9-b008-40c1-84a6-c350ec326840",
"name": "confirmation",
"type": "string",
"value": "All invoices have been processed"
}
]
}
},
"typeVersion": 3.4
},
{
"id": "82edfbf5-53d1-4105-ae08-85fdd4d4a5de",
"name": "파싱된 데이터",
"type": "n8n-nodes-base.set",
"position": [
-48,
1120
],
"parameters": {
"options": {
"ignoreConversionErrors": true
},
"assignments": {
"assignments": [
{
"id": "ac4cf2cc-36af-47a4-8638-852302ec2dbd",
"name": "parsedData",
"type": "object",
"value": "={{$json[\"candidates\"][0][\"content\"][\"parts\"][0][\"text\"].replace(/^```json\\s*|\\s*```$/g, '')}}\n"
}
]
}
},
"retryOnFail": true,
"typeVersion": 3.4
},
{
"id": "b5293bee-dadb-4de1-9142-4efaf432d90f",
"name": "PDF를 Google Gemini에 업로드",
"type": "n8n-nodes-base.httpRequest",
"position": [
-432,
1120
],
"parameters": {
"url": "https://generativelanguage.googleapis.com/upload/v1beta/files",
"method": "POST",
"options": {},
"sendBody": true,
"contentType": "binaryData",
"sendHeaders": true,
"authentication": "predefinedCredentialType",
"headerParameters": {
"parameters": [
{
"name": "Content-Type",
"value": "application/pdf"
}
]
},
"inputDataFieldName": "data0",
"nodeCredentialType": "googlePalmApi"
},
"credentials": {
"googlePalmApi": {
"id": "MVIooTcewmtXqO0w",
"name": "Google Gemini(PaLM) Api account"
},
"httpHeaderAuth": {
"id": "IQ2fzRRHdXqaY5q8",
"name": "Google API"
}
},
"typeVersion": 4.2
},
{
"id": "3679bcea-f0aa-4c4e-82b0-43c147564377",
"name": "Google Gemini에서 데이터 다운로드",
"type": "n8n-nodes-base.httpRequest",
"onError": "continueErrorOutput",
"position": [
-240,
1120
],
"parameters": {
"url": "https://generativelanguage.googleapis.com/v1beta/models/gemini-2.5-flash-preview-04-17:generateContent",
"method": "POST",
"options": {},
"jsonBody": "={\n \"contents\": [\n {\n \"role\": \"user\",\n \"parts\": [\n {\n \"text\": \"Read and analyze this document. If it is an invoice, extract and return the following fields in JSON format:\\\\n- Vendor Name\\\\n- Invoice Number\\\\n- Invoice Date\\\\n- Due Date\\\\n- Total Amount\\\\n- VAT Amount\\\\n- Line Items (Description, Quantity, Unit Price, Total Price)\\\\nIf it is not an invoice, summarize the document content instead in plain text.\"\n },\n {\n \"file_data\": {\n \"mime_type\": \"application/pdf\",\n \"file_uri\": {{ JSON.stringify($json.file.uri) }}\n }\n }\n ]\n }\n ],\n \"generationConfig\": {\n \"responseMimeType\": \"text/plain\",\n \"maxOutputTokens\": 32768\n }\n}\n",
"sendBody": true,
"sendHeaders": true,
"specifyBody": "json",
"authentication": "predefinedCredentialType",
"headerParameters": {
"parameters": [
{
"name": "Content-Type",
"value": "application/json"
}
]
},
"nodeCredentialType": "googlePalmApi"
},
"credentials": {
"googlePalmApi": {
"id": "MVIooTcewmtXqO0w",
"name": "Google Gemini(PaLM) Api account"
},
"httpHeaderAuth": {
"id": "IQ2fzRRHdXqaY5q8",
"name": "Google API"
}
},
"typeVersion": 4.2
},
{
"id": "2951c2d7-f543-4ea7-acdb-67b9fa9c8d31",
"name": "ERP 테이블",
"type": "n8n-nodes-base.googleSheets",
"position": [
288,
1120
],
"parameters": {
"columns": {
"value": {
"Due Date": "={{ $('Parsed Data').item.json.parsedData['Due Date'] }}",
"Quantity": "={{ $json.Quantity }}",
"Unit Price": "={{ $json['Unit Price'] }}",
"VAT Amount": "={{ $('Parsed Data').item.json.parsedData['VAT Amount'] }}",
"Total Price": "={{ $json['Total Price'] }}",
"Vendor Name": "={{ $('Parsed Data').item.json.parsedData['Vendor Name'] }}",
"Invoice Date": "={{ $('Parsed Data').item.json.parsedData['Invoice Date'] }}",
"Total Amount": "={{ $('Parsed Data').item.json.parsedData['Total Amount'] }}",
"Invoice Number": "={{ $('Parsed Data').item.json.parsedData['Invoice Number'] }}",
"Line Item Description": "={{ $json.Description }}"
},
"schema": [
{
"id": "Vendor Name",
"type": "string",
"display": true,
"required": false,
"displayName": "Vendor Name",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Invoice Number",
"type": "string",
"display": true,
"required": false,
"displayName": "Invoice Number",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Invoice Date",
"type": "string",
"display": true,
"required": false,
"displayName": "Invoice Date",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Due Date",
"type": "string",
"display": true,
"required": false,
"displayName": "Due Date",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Total Amount",
"type": "string",
"display": true,
"required": false,
"displayName": "Total Amount",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "VAT Amount",
"type": "string",
"display": true,
"required": false,
"displayName": "VAT Amount",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Line Item Description",
"type": "string",
"display": true,
"required": false,
"displayName": "Line Item Description",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Quantity",
"type": "string",
"display": true,
"required": false,
"displayName": "Quantity",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Unit Price",
"type": "string",
"display": true,
"required": false,
"displayName": "Unit Price",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Total Price",
"type": "string",
"display": true,
"required": false,
"displayName": "Total Price",
"defaultMatch": false,
"canBeUsedToMatch": true
}
],
"mappingMode": "defineBelow",
"matchingColumns": [],
"attemptToConvertTypes": false,
"convertFieldsToString": false
},
"options": {
"cellFormat": "USER_ENTERED"
},
"operation": "append",
"sheetName": {
"__rl": true,
"mode": "list",
"value": "gid=0",
"cachedResultUrl": "https://docs.google.com/spreadsheets/d/1Gjm3ALhZZ7I4Wto0CZYNuEr48K-bgLLK6M8K4eyuPq0/edit#gid=0",
"cachedResultName": "Sheet1"
},
"documentId": {
"__rl": true,
"mode": "list",
"value": "1Gjm3ALhZZ7I4Wto0CZYNuEr48K-bgLLK6M8K4eyuPq0",
"cachedResultUrl": "https://docs.google.com/spreadsheets/d/1Gjm3ALhZZ7I4Wto0CZYNuEr48K-bgLLK6M8K4eyuPq0/edit?usp=drivesdk",
"cachedResultName": "Test Invoice Records"
}
},
"credentials": {
"googleSheetsOAuth2Api": {
"id": "hgjZaSBUGfCSi6WA",
"name": "Google Sheets account"
}
},
"typeVersion": 4.5
},
{
"id": "d96a6fe2-fe52-4bdc-8199-7c5de0e18d03",
"name": "다른 워크플로우에 의해 실행 시",
"type": "n8n-nodes-base.executeWorkflowTrigger",
"disabled": true,
"position": [
-576,
-2048
],
"parameters": {},
"typeVersion": 1.1
},
{
"id": "60c60b57-a29c-4b84-a364-7ff194338a23",
"name": "병합",
"type": "n8n-nodes-base.merge",
"position": [
416,
912
],
"parameters": {},
"typeVersion": 3.1
},
{
"id": "67e50b05-8095-4733-b14d-aac6181163aa",
"name": "파일명 업데이트",
"type": "n8n-nodes-base.googleDrive",
"onError": "continueRegularOutput",
"position": [
592,
912
],
"parameters": {
"fileId": {
"__rl": true,
"mode": "id",
"value": "={{ $json.id }}"
},
"options": {},
"operation": "update",
"newUpdatedFileName": "={{$('Table ERP').first().json['Vendor Name']}} - {{$('Table ERP').first().json['Invoice Number']}}"
},
"credentials": {
"googleDriveOAuth2Api": {
"id": "nraVXtOxIKoXG4ac",
"name": "Google Drive AutoSolutions"
}
},
"typeVersion": 3
},
{
"id": "08e9f03b-c1b5-4d53-8d63-5be9c1f57187",
"name": "인보이스 저장",
"type": "n8n-nodes-base.googleDrive",
"position": [
-240,
912
],
"parameters": {
"name": "={{ $json.files[0].fileName }}",
"driveId": {
"__rl": true,
"mode": "list",
"value": "My Drive"
},
"options": {},
"folderId": {
"__rl": true,
"mode": "list",
"value": "1nCCa5nxntHv4u-2hSKG9K3cBxrQhA32O",
"cachedResultUrl": "https://drive.google.com/drive/folders/1nCCa5nxntHv4u-2hSKG9K3cBxrQhA32O",
"cachedResultName": "Invoices"
},
"inputDataFieldName": "data0"
},
"credentials": {
"googleDriveOAuth2Api": {
"id": "nraVXtOxIKoXG4ac",
"name": "Google Drive AutoSolutions"
}
},
"typeVersion": 3
},
{
"id": "65beec00-7e7f-4f2c-8e49-8c5bc9bcac5a",
"name": "스티커 노트",
"type": "n8n-nodes-base.stickyNote",
"position": [
-992,
832
],
"parameters": {
"color": 5,
"width": 1988,
"height": 528,
"content": "# Invoice Processing"
},
"typeVersion": 1
},
{
"id": "d9428d0b-67e2-4f01-af5c-418814e5adbf",
"name": "스티커 노트2",
"type": "n8n-nodes-base.stickyNote",
"position": [
-992,
-144
],
"parameters": {
"color": 5,
"width": 1604,
"height": 608,
"content": "# Expenses Processing"
},
"typeVersion": 1
},
{
"id": "49d55301-45d9-436a-be83-205938ac8e43",
"name": "스티커 노트3",
"type": "n8n-nodes-base.stickyNote",
"position": [
-976,
-64
],
"parameters": {
"width": 340,
"height": 480,
"content": "# Donna - Accountant\n\n\n\n"
},
"typeVersion": 1
},
{
"id": "c638cf56-555c-489d-bb83-bf385ae88af4",
"name": "Google Drive 트리거",
"type": "n8n-nodes-base.googleDriveTrigger",
"position": [
-544,
80
],
"parameters": {
"event": "fileCreated",
"options": {},
"pollTimes": {
"item": [
{
"mode": "everyMinute"
}
]
},
"triggerOn": "specificFolder",
"folderToWatch": {
"__rl": true,
"mode": "list",
"value": "1vBeKYr7XpinvUUCNYDKOiNIhNcDI5By_",
"cachedResultUrl": "https://drive.google.com/drive/folders/1vBeKYr7XpinvUUCNYDKOiNIhNcDI5By_",
"cachedResultName": "Expense Receipts"
}
},
"credentials": {
"googleDriveOAuth2Api": {
"id": "nraVXtOxIKoXG4ac",
"name": "Google Drive AutoSolutions"
}
},
"typeVersion": 1
},
{
"id": "947a8138-e565-4738-b1c8-8b85068ba6e4",
"name": "분할1",
"type": "n8n-nodes-base.splitOut",
"position": [
400,
-80
],
"parameters": {
"options": {},
"fieldToSplitOut": "parsedData['Line Items']"
},
"typeVersion": 1
},
{
"id": "df7a4279-7e74-4faf-8d5a-b87a657ce9d2",
"name": "파싱된 데이터1",
"type": "n8n-nodes-base.set",
"position": [
240,
-128
],
"parameters": {
"options": {
"ignoreConversionErrors": true
},
"assignments": {
"assignments": [
{
"id": "ac4cf2cc-36af-47a4-8638-852302ec2dbd",
"name": "parsedData",
"type": "object",
"value": "={{$json[\"candidates\"][0][\"content\"][\"parts\"][0][\"text\"].replace(/^```json\\s*|\\s*```$/g, '')}}\n"
}
]
}
},
"retryOnFail": true,
"typeVersion": 3.4
},
{
"id": "32e2ac3c-d6eb-404b-99df-0ed49d18b3fe",
"name": "PDF를 Google Gemini1에 업로드",
"type": "n8n-nodes-base.httpRequest",
"position": [
-160,
-128
],
"parameters": {
"url": "https://generativelanguage.googleapis.com/upload/v1beta/files",
"method": "POST",
"options": {},
"sendBody": true,
"contentType": "binaryData",
"sendHeaders": true,
"authentication": "predefinedCredentialType",
"headerParameters": {
"parameters": [
{
"name": "Content-Type",
"value": "application/pdf"
}
]
},
"inputDataFieldName": "data",
"nodeCredentialType": "googlePalmApi"
},
"credentials": {
"googlePalmApi": {
"id": "MVIooTcewmtXqO0w",
"name": "Google Gemini(PaLM) Api account"
},
"httpHeaderAuth": {
"id": "IQ2fzRRHdXqaY5q8",
"name": "Google API"
}
},
"typeVersion": 4.2
},
{
"id": "2a020ce2-5406-410f-8530-42c8abdc2128",
"name": "Google Gemini1에서 데이터 다운로드",
"type": "n8n-nodes-base.httpRequest",
"onError": "continueErrorOutput",
"position": [
32,
-128
],
"parameters": {
"url": "https://generativelanguage.googleapis.com/v1beta/models/gemini-2.5-flash-preview-04-17:generateContent",
"method": "POST",
"options": {},
"jsonBody": "={\n \"contents\": [\n {\n \"role\": \"user\",\n \"parts\": [\n {\n \"text\": \"Read and analyze this document. If it is an expense receipt, extract and return the following fields in JSON format:\\n- Merchant Name\\n- Transaction Date\\n- Total Amount\\n- Tax Amount (if available)\\n- Payment Method\\n- Line Items (Description, Quantity, Unit Price, Total Price) if available\\nIf it is not an expense receipt, summarize the document content instead in plain text.\"\n },\n {\n \"file_data\": {\n \"mime_type\": \"application/pdf\",\n \"file_uri\": {{ JSON.stringify($json.file.uri) }}\n }\n }\n ]\n }\n ],\n \"generationConfig\": {\n \"responseMimeType\": \"text/plain\",\n \"maxOutputTokens\": 32768\n }\n}\n",
"sendBody": true,
"sendHeaders": true,
"specifyBody": "json",
"authentication": "predefinedCredentialType",
"headerParameters": {
"parameters": [
{
"name": "Content-Type",
"value": "application/json"
}
]
},
"nodeCredentialType": "googlePalmApi"
},
"credentials": {
"googlePalmApi": {
"id": "MVIooTcewmtXqO0w",
"name": "Google Gemini(PaLM) Api account"
},
"httpHeaderAuth": {
"id": "IQ2fzRRHdXqaY5q8",
"name": "Google API"
}
},
"typeVersion": 4.2
},
{
"id": "0f89afbd-3b0b-48a6-b92d-838655f3424e",
"name": "Google Sheets",
"type": "n8n-nodes-base.googleSheets",
"position": [
192,
128
],
"parameters": {
"columns": {
"value": {
"Category": "={{ $json.output.category }}",
"Quantity": "={{ $('Split Out1').item.json.Quantity }}",
"Tax Amount": "={{ $('Parsed Data1').item.json.parsedData['Tax Amount'] }}",
"Unit Price": "={{ $('Split Out1').item.json['Unit Price'] }}",
"Total Price": "={{ $('Split Out1').item.json['Total Price'] }}",
"Total Amount": "={{ $('Parsed Data1').item.json.parsedData['Total Amount'] }}",
"Merchant Name": "={{ $('Parsed Data1').item.json.parsedData['Merchant Name'] }}",
"Payment Method": "={{ $('Parsed Data1').item.json.parsedData['Payment Method'] }}",
"Transaction Date": "={{ $('Parsed Data1').item.json.parsedData['Transaction Date'] }}",
"Line Item Description": "={{ $('Split Out1').item.json.Description }}"
},
"schema": [
{
"id": "Merchant Name",
"type": "string",
"display": true,
"required": false,
"displayName": "Merchant Name",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Transaction Date",
"type": "string",
"display": true,
"required": false,
"displayName": "Transaction Date",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Total Amount",
"type": "string",
"display": true,
"required": false,
"displayName": "Total Amount",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Tax Amount",
"type": "string",
"display": true,
"required": false,
"displayName": "Tax Amount",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Category",
"type": "string",
"display": true,
"removed": false,
"required": false,
"displayName": "Category",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Payment Method",
"type": "string",
"display": true,
"required": false,
"displayName": "Payment Method",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Line Item Description",
"type": "string",
"display": true,
"required": false,
"displayName": "Line Item Description",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Quantity",
"type": "string",
"display": true,
"required": false,
"displayName": "Quantity",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Unit Price",
"type": "string",
"display": true,
"required": false,
"displayName": "Unit Price",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Total Price",
"type": "string",
"display": true,
"required": false,
"displayName": "Total Price",
"defaultMatch": false,
"canBeUsedToMatch": true
}
],
"mappingMode": "defineBelow",
"matchingColumns": [],
"attemptToConvertTypes": false,
"convertFieldsToString": false
},
"options": {
"cellFormat": "USER_ENTERED"
},
"operation": "append",
"sheetName": {
"__rl": true,
"mode": "list",
"value": "gid=0",
"cachedResultUrl": "https://docs.google.com/spreadsheets/d/1zhOaSKk29dp0xzL8u3yVY62FEFxuo1I-9hc1pfAsQjs/edit#gid=0",
"cachedResultName": "Sheet1"
},
"documentId": {
"__rl": true,
"mode": "list",
"value": "1zhOaSKk29dp0xzL8u3yVY62FEFxuo1I-9hc1pfAsQjs",
"cachedResultUrl": "https://docs.google.com/spreadsheets/d/1zhOaSKk29dp0xzL8u3yVY62FEFxuo1I-9hc1pfAsQjs/edit?usp=drivesdk",
"cachedResultName": "Expenses Recording"
}
},
"credentials": {
"googleSheetsOAuth2Api": {
"id": "hgjZaSBUGfCSi6WA",
"name": "Google Sheets account"
}
},
"typeVersion": 4.5
},
{
"id": "dbe2be8e-98f0-4c74-81ef-b69d80e7759d",
"name": "Google Drive",
"type": "n8n-nodes-base.googleDrive",
"position": [
-368,
-128
],
"parameters": {
"fileId": {
"__rl": true,
"mode": "id",
"value": "={{ $json.id }}"
},
"options": {},
"operation": "download"
},
"credentials": {
"googleDriveOAuth2Api": {
"id": "nraVXtOxIKoXG4ac",
"name": "Google Drive AutoSolutions"
}
},
"typeVersion": 3
},
{
"id": "dc065b83-bae9-4cde-bfc4-2440964d600c",
"name": "스티커 노트4",
"type": "n8n-nodes-base.stickyNote",
"position": [
-992,
-1136
],
"parameters": {
"color": 5,
"width": 2136,
"height": 512,
"content": "# Expenses Processing"
},
"typeVersion": 1
},
{
"id": "84d2f0ab-ae05-452b-8b00-76c74f167959",
"name": "스티커 노트5",
"type": "n8n-nodes-base.stickyNote",
"position": [
-976,
-1056
],
"parameters": {
"width": 340,
"height": 420,
"content": "# Victor - Controller\n\n\n"
},
"typeVersion": 1
},
{
"id": "f8c79b50-6d77-45f1-b7df-4b48a992402d",
"name": "Google Drive 트리거1",
"type": "n8n-nodes-base.googleDriveTrigger",
"position": [
-480,
-976
],
"parameters": {
"event": "fileCreated",
"options": {},
"pollTimes": {
"item": [
{
"mode": "everyMinute"
}
]
},
"triggerOn": "specificFolder",
"folderToWatch": {
"__rl": true,
"mode": "list",
"value": "16l6LegAqkV6axZT9WPwr_p2-20VqeiRD",
"cachedResultUrl": "https://drive.google.com/drive/folders/16l6LegAqkV6axZT9WPwr_p2-20VqeiRD",
"cachedResultName": "Bank Statements"
}
},
"credentials": {
"googleDriveOAuth2Api": {
"id": "nraVXtOxIKoXG4ac",
"name": "Google Drive AutoSolutions"
}
},
"typeVersion": 1
},
{
"id": "529732d1-eee3-471d-80b7-0ac6320ed6d2",
"name": "PDF를 Google Gemini2에 업로드",
"type": "n8n-nodes-base.httpRequest",
"position": [
48,
-976
],
"parameters": {
"url": "https://generativelanguage.googleapis.com/upload/v1beta/files",
"method": "POST",
"options": {},
"sendBody": true,
"contentType": "binaryData",
"sendHeaders": true,
"authentication": "predefinedCredentialType",
"headerParameters": {
"parameters": [
{
"name": "Content-Type",
"value": "application/pdf"
}
]
},
"inputDataFieldName": "data",
"nodeCredentialType": "googlePalmApi"
},
"credentials": {
"googlePalmApi": {
"id": "MVIooTcewmtXqO0w",
"name": "Google Gemini(PaLM) Api account"
},
"httpHeaderAuth": {
"id": "IQ2fzRRHdXqaY5q8",
"name": "Google API"
}
},
"typeVersion": 4.2
},
{
"id": "1765ea24-57c2-4c5f-9ca0-70338934195d",
"name": "Google Gemini2에서 데이터 다운로드",
"type": "n8n-nodes-base.httpRequest",
"onError": "continueErrorOutput",
"position": [
256,
-976
],
"parameters": {
"url": "https://generativelanguage.googleapis.com/v1beta/models/gemini-2.5-flash-preview-04-17:generateContent",
"method": "POST",
"options": {},
"jsonBody": "={\n \"contents\": [\n {\n \"role\": \"user\",\n \"parts\": [\n {\n \"text\": \"Read and analyze this document. If it is a bank statement, extract and return the following fields in JSON format:\\n- Txn ID\\n- Date\\n- Description / Payee\\n- Debit (-)\\n- Credit (+)\\n- Currency\\n- Running Balance\\n- Notes / Category (optional)\\n\\nIf it is not a bank statement, summarize the document content instead in plain text.\"\n },\n {\n \"file_data\": {\n \"mime_type\": \"application/pdf\",\n \"file_uri\": {{ JSON.stringify($json.file.uri) }}\n }\n }\n ]\n }\n ],\n \"generationConfig\": {\n \"responseMimeType\": \"text/plain\",\n \"maxOutputTokens\": 32768\n }\n}\n",
"sendBody": true,
"sendHeaders": true,
"specifyBody": "json",
"authentication": "predefinedCredentialType",
"headerParameters": {
"parameters": [
{
"name": "Content-Type",
"value": "application/json"
}
]
},
"nodeCredentialType": "googlePalmApi"
},
"credentials": {
"googlePalmApi": {
"id": "MVIooTcewmtXqO0w",
"name": "Google Gemini(PaLM) Api account"
},
"httpHeaderAuth": {
"id": "IQ2fzRRHdXqaY5q8",
"name": "Google API"
}
},
"typeVersion": 4.2
},
{
"id": "6d94b80f-914f-4c60-b0b8-1fec176ba707",
"name": "Google Sheets1",
"type": "n8n-nodes-base.googleSheets",
"position": [
736,
-976
],
"parameters": {
"columns": {
"value": {
"Date": "={{ $json.Date }}",
"Currency": "={{ $json.Currency }}",
"Debit (-)": "={{ $json['Debit (-)'] }}",
"Credit (+)": "={{ $json['Credit (+)'] }}",
"Running Balance": "={{ $json['Running Balance'] }}",
"Description / Payee": "={{ $json['Description / Payee'] }}"
},
"schema": [
{
"id": "Transaction ID",
"type": "string",
"display": true,
"removed": false,
"required": false,
"displayName": "Transaction ID",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Date",
"type": "string",
"display": true,
"removed": false,
"required": false,
"displayName": "Date",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Description / Payee",
"type": "string",
"display": true,
"removed": false,
"required": false,
"displayName": "Description / Payee",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Debit (-)",
"type": "string",
"display": true,
"removed": false,
"required": false,
"displayName": "Debit (-)",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Credit (+)",
"type": "string",
"display": true,
"removed": false,
"required": false,
"displayName": "Credit (+)",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Currency",
"type": "string",
"display": true,
"removed": false,
"required": false,
"displayName": "Currency",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Running Balance",
"type": "string",
"display": true,
"removed": false,
"required": false,
"displayName": "Running Balance",
"defaultMatch": false,
"canBeUsedToMatch": true
},
{
"id": "Notes / Category",
"type": "string",
"display": true,
"removed": false,
"required": false,
"displayName": "Notes / Category",
"defaultMatch": false,
"canBeUsedToMatch": true
}
],
"mappingMode": "defineBelow",
"matchingColumns": [],
"attemptToConvertTypes": false,
"convertFieldsToString": false
},
"options": {
"cellFormat": "USER_ENTERED"
},
"operation": "append",
"sheetName": {
"__rl": true,
"mode": "list",
"value": "gid=0",
"cachedResultUrl": "https://docs.google.com/spreadsheets/d/1SOknw2I6hgXwwaaRHPPogtGjCP4pUjK-xsfIYYwJnvo/edit#gid=0",
"cachedResultName": "Sheet1"
},
"documentId": {
"__rl": true,
"mode": "list",
"value": "1SOknw2I6hgXwwaaRHPPogtGjCP4pUjK-xsfIYYwJnvo",
"cachedResultUrl": "https://docs.google.com/spreadsheets/d/1SOknw2I6hgXwwaaRHPPogtGjCP4pUjK-xsfIYYwJnvo/edit?usp=drivesdk",
"cachedResultName": "Bank Transactions Record"
}
},
"credentials": {
"googleSheetsOAuth2Api": {
"id": "hgjZaSBUGfCSi6WA",
"name": "Google Sheets account"
}
},
"typeVersion": 4.5
},
{
"id": "55f393cc-9c47-42db-8803-f1e090459605",
"name": "Google Drive1",
"type": "n8n-nodes-base.googleDrive",
"position": [
-256,
-976
],
"parameters": {
"fileId": {
"__rl": true,
"mode": "id",
"value": "={{ $json.id }}"
},
"options": {},
"operation": "download"
},
"credentials": {
"googleDriveOAuth2Api": {
"id": "nraVXtOxIKoXG4ac",
"name": "Google Drive AutoSolutions"
}
},
"typeVersion": 3
},
{
"id": "4b5d634e-53f9-41d5-938c-7cf6efe61411",
"name": "필드 편집",
"type": "n8n-nodes-base.set",
"position": [
912,
-976
],
"parameters": {
"options": {},
"assignments": {
"assignments": [
{
"id": "9f21fb2a-c48b-4918-ba56-c98384e1546d",
"name": "response",
"type": "string",
"value": "Recorded!"
}
]
}
},
"typeVersion": 3.4
},
{
"id": "03bc404a-d364-42b4-900f-ca61e4dd9b67",
"name": "필드 편집1",
"type": "n8n-nodes-base.set",
"position": [
400,
128
],
"parameters": {
"options": {},
"assignments": {
"assignments": [
{
"id": "9f21fb2a-c48b-4918-ba56-c98384e1546d",
"name": "response",
"type": "string",
"value": "Recorded!"
}
]
}
},
"typeVersion": 3.4
},
{
"id": "347e16d9-febc-4f44-8539-112ca95e3df5",
"name": "코드",
"type": "n8n-nodes-base.code",
"position": [
512,
-976
],
"parameters": {
"jsCode": "const raw = $json.candidates[0].content.parts[0].text;\nconst match = raw.match(/```json\\s*([\\s\\S]*?)\\s*```/);\nlet body = (match ? match[1] : raw)\n\t .replace(/[\\u0000-\\u001F\\u007F-\\u009F]/g, '')\n\t .replace(/,\\s*([}\\]])/g, '$1');\n\nlet data;\ntry {\n\tdata = JSON.parse(body); // ← will throw a readable n8n error if still bad\n} catch (err) {\n\tthrow new Error('LLM returned invalid JSON ➜ ' + err.message);\n}\n\n// Normalise: array of rows no matter what\nif (!Array.isArray(data)) data = data.transactions || [data];\nreturn data.map(t => ({ json: t }));\n"
},
"typeVersion": 2
},
{
"id": "5ebbafe9-d67e-4e86-be8c-e02c79f177d4",
"name": "기본 LLM 체인",
"type": "@n8n/n8n-nodes-langchain.chainLlm",
"position": [
-160,
128
],
"parameters": {
"text": "={{ $('Download Data from Google Gemini1').item.json.candidates[0].content.parts[0].text }}",
"messages": {
"messageValues": [
{
"message": "=You are EXPENSE-CLASSIFIER, an expert bookkeeping agent.\n\nTask \n• Read the input text of one expense (bank-transaction line, receipt, or invoice memo). \n• Choose exactly **one** category from the allowed list below that best fits. \n• If no perfect fit exists, pick the closest logical category (never return “unknown”). \n• Respond ONLY with valid JSON that matches the schema in the next block—no extra keys, no markdown.\n\nAllowed categories \n- Cost of Goods Sold \n- Advertising & Marketing \n- Payroll & Wages \n- Employee Benefits \n- Contract Labor \n- Rent & Leases \n- Utilities \n- Office Supplies & G&A \n- Software & Cloud Subscriptions \n- Travel Meals & Entertainment \n- Professional Services \n- Insurance \n- Repairs & Maintenance \n- Taxes & Licenses \n- Interest Expense \n- Depreciation & Amortization \n- Other Miscellaneous\n"
}
]
},
"promptType": "define",
"hasOutputParser": true
},
"typeVersion": 1.6
},
{
"id": "f1a9203a-0d21-46f0-aa9a-afff675427dc",
"name": "OpenRouter 채팅 모델",
"type": "@n8n/n8n-nodes-langchain.lmChatOpenRouter",
"position": [
-160,
304
],
"parameters": {
"options": {}
},
"credentials": {
"openRouterApi": {
"id": "9fwHsRBaQUkeEsGv",
"name": "OpenRouter ML Account"
}
},
"typeVersion": 1
},
{
"id": "9638204f-cb80-4fb5-a146-055160fd1437",
"name": "구조화 출력 파서",
"type": "@n8n/n8n-nodes-langchain.outputParserStructured",
"position": [
-16,
304
],
"parameters": {
"jsonSchemaExample": "{\n \"category\": \"Advertising & Marketing\"\n}\n"
},
"typeVersion": 1.2
},
{
"id": "1cbde03d-4562-4b08-9001-e3e13bc7cf9b",
"name": "AI 에이전트",
"type": "@n8n/n8n-nodes-langchain.agent",
"position": [
-352,
-2048
],
"parameters": {
"text": "={{ $json }}",
"options": {
"systemMessage": "You are FinanceDataBot, a specialized agent for extracting and analyzing financial data from spreadsheets.\n\nPRIMARY FUNCTION:\nYour sole purpose is to access, extract, and analyze data from financial spreadsheets when requested by an orchestrator agent. You have access to three key spreadsheets:\n1. Invoices - Contains invoice records with details on clients, amounts, dates, and payment status\n2. Expenses - Contains expense records with categories, amounts, dates, and other relevant details\n3. Transactions - Contains bank transaction records with dates, descriptions, amounts, and transaction types\n\nRESPONSE GUIDELINES:\n1. Always respond with accurate, concise data extractions based on the specific request\n2. Format numerical data appropriately (currency with 2 decimal places)\n3. When providing lists, use clean table formatting\n4. Include summary statistics when appropriate (totals, averages, etc.)\n5. Never share opinions or engage in casual conversation - stay focused on data extraction only\n\nDATA EXTRACTION CAPABILITIES:\n- Filter by date ranges (e.g., \"invoices for December\")\n- Sort and limit results (e.g., \"last 10 transactions\")\n- Calculate aggregates (e.g., \"total value of invoices\")\n- Perform basic analysis (e.g., \"highest expense category\")\n- Identify patterns or anomalies when specifically requested\n\nERROR HANDLING:\n- If data is missing or unavailable, clearly state what information could not be retrieved\n- If a request is ambiguous, ask for clarification on specific parameters needed\n- If a request is outside your capabilities, explain what you can and cannot provide\n\nSECURITY CONSIDERATIONS:\n- You only have access to the three specified spreadsheets\n- Do not attempt to access or modify any other data sources\n- Treat all financial data as confidential\n\nExample requests you should be able to handle:\n- \"What are the last 10 bank transactions?\"\n- \"What is the total value of invoices for December 2023?\"\n- \"List all unpaid invoices sorted by amount\"\n- \"What was our highest expense category last month?\"\n- \"Show me transactions over $1000 in the past week\"\n- \"Calculate the average invoice amount by client\""
},
"promptType": "define"
},
"typeVersion": 1.9
},
{
"id": "a0d38cbe-d401-458d-afde-7b46172f1b9a",
"name": "OpenRouter 채팅 모델1",
"type": "@n8n/n8n-nodes-langchain.lmChatOpenRouter",
"position": [
-448,
-1808
],
"parameters": {
"model": "openai/gpt-4.1",
"options": {}
},
"credentials": {
"openRouterApi": {
"id": "9fwHsRBaQUkeEsGv",
"name": "OpenRouter ML Account"
}
},
"typeVersion": 1
},
{
"id": "8fea6832-8064-46d3-a71e-eb42b325e58b",
"name": "인보이스",
"type": "n8n-nodes-base.googleSheetsTool",
"position": [
-128,
-1808
],
"parameters": {
"options": {
"dataLocationOnSheet": {
"values": {
"rangeDefinition": "detectAutomatically"
}
}
},
"sheetName": {
"__rl": true,
"mode": "list",
"value": "gid=0",
"cachedResultUrl": "https://docs.google.com/spreadsheets/d/1Gjm3ALhZZ7I4Wto0CZYNuEr48K-bgLLK6M8K4eyuPq0/edit#gid=0",
"cachedResultName": "Sheet1"
},
"documentId": {
"__rl": true,
"mode": "list",
"value": "1Gjm3ALhZZ7I4Wto0CZYNuEr48K-bgLLK6M8K4eyuPq0",
"cachedResultUrl": "https://docs.google.com/spreadsheets/d/1Gjm3ALhZZ7I4Wto0CZYNuEr48K-bgLLK6M8K4eyuPq0/edit?usp=drivesdk",
"cachedResultName": "Test Invoice Records"
}
},
"credentials": {
"googleSheetsOAuth2Api": {
"id": "hgjZaSBUGfCSi6WA",
"name": "Google Sheets account"
}
},
"typeVersion": 4.5
},
{
"id": "39e1c9dd-e85d-4548-8c62-24209f4b8fc0",
"name": "경비",
"type": "n8n-nodes-base.googleSheetsTool",
"position": [
-32,
-1808
],
"parameters": {
"options": {
"dataLocationOnSheet": {
"values": {
"rangeDefinition": "detectAutomatically"
}
}
},
"sheetName": {
"__rl": true,
"mode": "list",
"value": "gid=0",
"cachedResultUrl": "https://docs.google.com/spreadsheets/d/1zhOaSKk29dp0xzL8u3yVY62FEFxuo1I-9hc1pfAsQjs/edit#gid=0",
"cachedResultName": "Sheet1"
},
"documentId": {
"__rl": true,
"mode": "list",
"value": "1zhOaSKk29dp0xzL8u3yVY62FEFxuo1I-9hc1pfAsQjs",
"cachedResultUrl": "https://docs.google.com/spreadsheets/d/1zhOaSKk29dp0xzL8u3yVY62FEFxuo1I-9hc1pfAsQjs/edit?usp=drivesdk",
"cachedResultName": "Expenses Recording"
}
},
"credentials": {
"googleSheetsOAuth2Api": {
"id": "hgjZaSBUGfCSi6WA",
"name": "Google Sheets account"
}
},
"typeVersion": 4.5
},
{
"id": "df86bfde-6554-4bfd-8cfe-3cc2cfc6d4f8",
"name": "거래",
"type": "n8n-nodes-base.googleSheetsTool",
"position": [
64,
-1808
],
"parameters": {
"options": {
"dataLocationOnSheet": {
"values": {
"rangeDefinition": "detectAutomatically"
}
}
},
"sheetName": {
"__rl": true,
"mode": "list",
"value": "gid=0",
"cachedResultUrl": "https://docs.google.com/spreadsheets/d/1SOknw2I6hgXwwaaRHPPogtGjCP4pUjK-xsfIYYwJnvo/edit#gid=0",
"cachedResultName": "Sheet1"
},
"documentId": {
"__rl": true,
"mode": "list",
"value": "1SOknw2I6hgXwwaaRHPPogtGjCP4pUjK-xsfIYYwJnvo",
"cachedResultUrl": "https://docs.google.com/spreadsheets/d/1SOknw2I6hgXwwaaRHPPogtGjCP4pUjK-xsfIYYwJnvo/edit?usp=drivesdk",
"cachedResultName": "Bank Transactions Record"
}
},
"credentials": {
"googleSheetsOAuth2Api": {
"id": "hgjZaSBUGfCSi6WA",
"name": "Google Sheets account"
}
},
"typeVersion": 4.5
},
{
"id": "bf1db04b-5b67-4334-ab21-1e6e4d40fa6a",
"name": "필드 편집2",
"type": "n8n-nodes-base.set",
"position": [
0,
-2048
],
"parameters": {
"options": {},
"assignments": {
"assignments": [
{
"id": "599d7fa9-e8c5-4c3a-8957-f94c498014bd",
"name": "Response",
"type": "string",
"value": "={{ $json }}"
}
]
}
},
"typeVersion": 3.4
},
{
"id": "64afa6b9-e8eb-4d73-b124-c19f4051e75d",
"name": "스티커 노트6",
"type": "n8n-nodes-base.stickyNote",
"position": [
-960,
-2080
],
"parameters": {
"width": 340,
"height": 420,
"content": "# Andrew - CFO\n\n\n"
},
"typeVersion": 1
},
{
"id": "583b7a38-910e-4c9f-8c8d-cd0997addc60",
"name": "스티커 노트7",
"type": "n8n-nodes-base.stickyNote",
"position": [
-976,
-2160
],
"parameters": {
"color": 5,
"width": 1232,
"height": 520,
"content": "# Finance\n"
},
"typeVersion": 1
},
{
"id": "953aaa49-78d5-44b3-846b-c139b2c1d9cb",
"name": "스티커 노트25",
"type": "n8n-nodes-base.stickyNote",
"position": [
-3792,
1104
],
"parameters": {
"color": 7,
"width": 1344,
"height": 816,
"content": "# AutoSolutions.ai - AI Consulting Services\n## Didac Fernandez Girona\n\n\n\n"
},
"typeVersion": 1
},
{
"id": "b39dfed5-8164-4ea1-939f-6ed5ade480ba",
"name": "스티커 노트9",
"type": "n8n-nodes-base.stickyNote",
"position": [
-3984,
-2480
],
"parameters": {
"width": 784,
"height": 2256,
"content": "# 🤖 AI-Powered Financial Document Processing Workflow\n\n## 📋 Overview\nThis comprehensive workflow automates financial document processing using AI, handling invoices, expense receipts, and bank statements. It features four AI personas representing different financial roles and automatically extracts, categorizes, and stores financial data in Google Sheets.\n\n## ⭐ Key Features\n- 📄 **Multi-Document Support**: Processes invoices, expense receipts, and bank statements\n- 🧠 **AI-Powered Extraction**: Uses Google Gemini for intelligent data extraction\n- 🏷️ **Automatic Categorization**: Smart expense categorization with 17 predefined categories\n- 💬 **Financial Analysis Agent**: Query your financial data using natural language\n- 📁 **Automated File Management**: Renames and organizes processed documents\n- 👥 **Role-Based Processing**: Four distinct AI personas for different financial functions\n\n## 🔧 Workflow Components\n\n### 1. 📄 Invoice Processing (Mark - Accountant)\n**🚀 Trigger**: Chat interface for invoice uploads\n**⚙️ Process**:\n- 📤 Upload invoice via chat interface\n- 🧠 AI extracts: Vendor Name, Invoice Number, Invoice Date, Due Date, Total Amount, VAT Amount, Line Items\n- 📊 Data saved to \"Test Invoice Records\" Google Sheet\n- 📝 File automatically renamed as \"{Vendor Name} - {Invoice Number}\"\n- ✅ Confirmation message sent\n\n### 2. 🧾 Expense Processing (Donna - Accountant)\n**🚀 Trigger**: Google Drive folder monitoring (\"Expense Receipts\")\n**⚙️ Process**:\n- ⏰ Monitors expense receipts folder every minute\n- 🧠 AI extracts: Merchant Name, Transaction Date, Total Amount, Tax Amount, Payment Method, Line Items\n- 🏷️ Automatic expense categorization using predefined categories\n- 📊 Data saved to \"Expenses Recording\" Google Sheet\n\n**📋 Expense Categories**:\n- 📦 Cost of Goods Sold\n- 📢 Advertising & Marketing\n- 💰 Payroll & Wages\n- 🎯 Employee Benefits\n- 🤝 Contract Labor\n- 🏢 Rent & Leases\n- ⚡ Utilities\n- 📎 Office Supplies & G&A\n- 💻 Software & Cloud Subscriptions\n- ✈️ Travel Meals & Entertainment\n- 👔 Professional Services\n- 🛡️ Insurance\n- 🔧 Repairs & Maintenance\n- 🏛️ Taxes & Licenses\n- 💳 Interest Expense\n- 📉 Depreciation & Amortization\n- 📋 Other Miscellaneous\n\n### 3. 🏦 Bank Statement Processing (Victor - Controller)\n**🚀 Trigger**: Google Drive folder monitoring (\"Bank Statements\")\n**⚙️ Process**:\n- ⏰ Monitors bank statements folder every minute\n- 🧠 AI extracts: Transaction ID, Date, Description/Payee, Debit/Credit, Currency, Running Balance\n- 📊 Data saved to \"Bank Transactions Record\" Google Sheet\n\n### 4. 📈 Financial Analysis Agent (Andrew - CFO)\n**🚀 Trigger**: Manual execution for financial queries\n**🎯 Capabilities**:\n- 🗃️ Access to all three financial spreadsheets\n- 💬 Natural language queries about financial data\n- 📊 Generate reports and insights\n- ❓ Answer questions about invoices, expenses, and transactions\n\n## 🛠️ Setup Requirements\n\n### 🌐 Google Services\n1. **🚗 Google Drive API** credentials configured\n2. **📊 Google Sheets API** credentials configured \n3. **🧠 Google Gemini API** credentials configured\n4. **🤖 OpenRouter API** credentials for LLM categorization\n\n### 📁 Required Google Drive Folders\nCreate these folders in your Google Drive:\n- 📄 \"Invoices\" (for processed invoice storage)\n- 🧾 \"Expense Receipts\" (monitored for new expense receipts)\n- 🏦 \"Bank Statements\" (monitored for new bank statements)\n\n### 📊 Required Google Sheets\nCreate these spreadsheets with appropriate column headers:\n1. **📄 \"Test Invoice Records\"** - Vendor Name, Invoice Number, Invoice Date, Due Date, Total Amount, VAT Amount, Line Item Description, Quantity, Unit Price, Total Price\n2. **🧾 \"Expenses Recording\"** - Merchant Name, Transaction Date, Total Amount, Tax Amount, Payment Method, Line Item Description, Quantity, Unit Price, Total Price, Category\n3. **🏦 \"Bank Transactions Record\"** - Transaction ID, Date, Description/Payee, Debit (-), Credit (+), Currency, Running Balance, Notes/Category\n\n"
},
"typeVersion": 1
},
{
"id": "82e8c619-a09b-42bf-b6b9-773d20e821ac",
"name": "스티커 노트10",
"type": "n8n-nodes-base.stickyNote",
"position": [
-3120,
-848
],
"parameters": {
"width": 784,
"height": 640,
"content": "# 🛠️ Setup Requirements\n\n### 🌐 Google Services\n1. **🚗 Google Drive API** credentials configured\n2. **📊 Google Sheets API** credentials configured \n3. **🧠 Google Gemini API** credentials configured\n4. **🤖 OpenRouter API** credentials for LLM categorization\n\n### 📁 Required Google Drive Folders\nCreate these folders in your Google Drive:\n- 📄 \"Invoices\" (for processed invoice storage)\n- 🧾 \"Expense Receipts\" (monitored for new expense receipts)\n- 🏦 \"Bank Statements\" (monitored for new bank statements)\n\n### 📊 Required Google Sheets\nCreate these spreadsheets with appropriate column headers:\n1. **📄 \"Test Invoice Records\"** - Vendor Name, Invoice Number, Invoice Date, Due Date, Total Amount, VAT Amount, Line Item Description, Quantity, Unit Price, Total Price\n2. **🧾 \"Expenses Recording\"** - Merchant Name, Transaction Date, Total Amount, Tax Amount, Payment Method, Line Item Description, Quantity, Unit Price, Total Price, Category\n3. **🏦 \"Bank Transactions Record\"** - Transaction ID, Date, Description/Payee, Debit (-), Credit (+), Currency, Running Balance, Notes/Category\n\n"
},
"typeVersion": 1
},
{
"id": "d842268b-9d80-42da-952c-a0681736a584",
"name": "스티커 노트11",
"type": "n8n-nodes-base.stickyNote",
"position": [
-3120,
-2480
],
"parameters": {
"width": 784,
"height": 1600,
"content": "# 🎯 How to Use\n\n### 📄 Processing Invoices\n1. 💬 Access the chat interface\n2. 📤 Upload PDF invoice files\n3. ⏳ Wait for AI processing and confirmation\n4. ✅ Check \"Test Invoice Records\" Google Sheet for extracted data\n5. 📁 Processed files will be renamed and stored in \"Invoices\" folder\n\n### 🧾 Processing Expense Receipts\n1. 📤 Upload PDF receipts to \"Expense Receipts\" Google Drive folder\n2. ⚙️ Workflow automatically processes new files every minute\n3. ✅ Check \"Expenses Recording\" Google Sheet for categorized expenses\n4. 🏷️ AI automatically assigns appropriate expense categories\n\n### 🏦 Processing Bank Statements\n1. 📤 Upload PDF bank statements to \"Bank Statements\" Google Drive folder\n2. ⚙️ Workflow automatically processes new files every minute\n3. ✅ Check \"Bank Transactions Record\" Google Sheet for transaction data\n\n### 💬 Querying Financial Data\n1. ▶️ Execute the \"When Executed by Another Workflow\" trigger\n2. 🗣️ Send natural language queries about your financial data\n3. 💡 Examples:\n - \"What are the last 10 bank transactions?\"\n - \"What is the total value of invoices for December 2023?\"\n - \"List all unpaid invoices sorted by amount\"\n - \"What was our highest expense category last month?\"\n - \"Show me transactions over $1000 in the past week\"\n\n## 📁 Supported File Formats\n- **📄 PDF files only** (invoices, receipts, bank statements)\n- 🔍 Ensure documents are clear and legible for optimal AI extraction\n\n## ⚠️ Error Handling\n- ✅ Workflow continues processing even if individual documents fail\n- 📝 Error outputs are logged for troubleshooting\n- 🔧 Failed extractions can be manually reviewed and corrected\n\n## 👥 AI Personas\n- **📄 Mark (Accountant)**: Handles invoice processing with attention to vendor details and payment terms\n- **🧾 Donna (Accountant)**: Manages expense categorization and receipt processing\n- **🏦 Victor (Controller)**: Oversees bank statement processing and transaction reconciliation\n- **📈 Andrew (CFO)**: Provides high-level financial analysis and reporting\n\n## 🎉 Benefits\n- ⏰ **Time Savings**: Automates manual data entry from financial documents\n- 🎯 **Accuracy**: AI-powered extraction reduces human error\n- 📂 **Organization**: Automatic file naming and categorization\n- 💡 **Insights**: Query financial data using natural language\n- 📈 **Scalability**: Processes multiple documents simultaneously\n- 🛡️ **Compliance**: Maintains organized records for accounting and audit purposes\n\n## 🔧 Troubleshooting\n- ✅ Ensure all API credentials are properly configured\n- 📁 Verify Google Drive folder permissions allow the workflow to access files\n- 📊 Check that Google Sheets have the correct column headers\n- 📝 Monitor workflow execution logs for any processing errors\n- 📄 Test with clear, high-quality PDF documents for best resultshooting\n- Ensure all API credentials are properly configured\n- Verify Google Drive folder permissions allow the workflow to access files\n- Check that Google Sheets have the correct column headers\n- Monitor workflow execution logs for any processing errors\n- Test with clear, high-quality PDF documents for best results"
},
"typeVersion": 1
},
{
"id": "114a10ca-24f0-492d-af38-45795bab1666",
"name": "📄 인보이스 처리 문서화",
"type": "n8n-nodes-base.stickyNote",
"position": [
-2224,
816
],
"parameters": {
"color": 5,
"width": 772,
"height": 1112,
"content": "# 📄 INVOICE PROCESSING SECTION\n\n## 🎯 Purpose\nThis section handles invoice processing through a chat interface. Mark, the AI Accountant, extracts key invoice data and stores it in Google Sheets.\n\n## 🔄 Process Flow\n1. **💬 Chat Trigger**: Users upload PDF invoices via chat\n2. **📁 File Storage**: Invoice saved to Google Drive \"Invoices\" folder\n3. **🤖 AI Processing**: Google Gemini extracts invoice data\n4. **📊 Data Storage**: Information saved to \"Test Invoice Records\" spreadsheet\n5. **📝 File Renaming**: File renamed as \"{Vendor Name} - {Invoice Number}\"\n6. **✅ Confirmation**: Success message sent to user\n\n## 📋 Extracted Fields\n- Vendor Name\n- Invoice Number\n- Invoice Date\n- Due Date\n- Total Amount\n- VAT Amount\n- Line Items (Description, Quantity, Unit Price, Total Price)\n\n## ⚙️ Configuration Notes\n- Chat trigger allows all file types but processes PDF only\n- Error handling continues processing even if extraction fails\n- Files are stored with original name then renamed after processing"
},
"typeVersion": 1
},
{
"id": "b838b4c4-545c-411d-b6cd-9041479f72e9",
"name": "Mark - 회계사",
"type": "n8n-nodes-base.stickyNote",
"position": [
-1344,
832
],
"parameters": {
"color": 6,
"width": 324,
"height": 528,
"content": "# Mark - Accountant 👨💼\n\n**Role**: Invoice Processing Specialist\n\n**Responsibilities**:\n- ✅ Extract vendor information\n- ✅ Capture payment terms\n- ✅ Process line item details\n- ✅ Ensure data accuracy\n\n**AI Capabilities**:\n- 🧠 Intelligent field recognition\n- 📋 Structured data extraction\n- 🔍 Quality validation"
},
"typeVersion": 1
},
{
"id": "de948508-c38d-47aa-9a57-3972a854fd3f",
"name": "💾 파일 저장 안내",
"type": "n8n-nodes-base.stickyNote",
"position": [
-1344,
1392
],
"parameters": {
"color": 3,
"width": 268,
"height": 488,
"content": "# 📤 STEP 1: File Upload & Storage\n\n**Purpose**: Save uploaded invoice to Google Drive\n\n**Configuration**:\n- 📁 Target Folder: \"Invoices\"\n- 📄 Input Field: data0 (from chat upload)\n- 📝 Filename: Uses original uploaded filename\n\n**Output**: File ID and metadata for downstream processing"
},
"typeVersion": 1
},
{
"id": "d76a1641-f669-4ca7-a72e-ea3a5f3cd6c9",
"name": "🤖 AI 업로드 안내",
"type": "n8n-nodes-base.stickyNote",
"position": [
-1056,
1392
],
"parameters": {
"color": 3,
"width": 220,
"height": 488,
"content": "# 🤖 STEP 2: AI Upload\n\n**Purpose**: Upload PDF to Google Gemini for processing\n\n**Configuration**:\n- 🔗 Endpoint: Gemini File Upload API\n- 📄 Content-Type: application/pdf\n- 🔐 Auth: Google PaLM API credentials\n- 📊 Input: Binary data from chat upload\n\n**Output**: File URI for Gemini processing"
},
"typeVersion": 1
},
{
"id": "f91e1f93-c743-400a-bbd9-520edd6169d0",
"name": "🧠 데이터 추출 안내",
"type": "n8n-nodes-base.stickyNote",
"position": [
-816,
1392
],
"parameters": {
"color": 3,
"width": 252,
"height": 488,
"content": "# 🧠 STEP 3: Data Extraction\n\n**Purpose**: Use Gemini AI to extract structured invoice data\n\n**AI Prompt**: Extracts:\n- 🏢 Vendor Name\n- 🔢 Invoice Number\n- 📅 Invoice Date\n- 📅 Due Date\n- 💰 Total Amount\n- 💰 VAT Amount\n- 📋 Line Items\n\n**Output**: JSON structured data or plain text summary"
},
"typeVersion": 1
},
{
"id": "aa42f2bd-4ee3-45f3-a671-33eff825a42e",
"name": "📋 JSON 파싱 안내",
"type": "n8n-nodes-base.stickyNote",
"position": [
-544,
1392
],
"parameters": {
"color": 3,
"width": 236,
"height": 488,
"content": "# 📋 STEP 4: JSON Parsing\n\n**Purpose**: Clean and parse AI response into structured data\n\n**Process**:\n- 🧹 Remove markdown code blocks\n- 📊 Convert text to JSON object\n- ⚠️ Handle parsing errors gracefully\n- 🔄 Retry on failure\n\n**Output**: Clean parsedData object for spreadsheet"
},
"typeVersion": 1
},
{
"id": "4207bb87-5651-4107-afd1-c74fa3ffe2e9",
"name": "📑 항목 분할 안내",
"type": "n8n-nodes-base.stickyNote",
"position": [
-288,
1392
],
"parameters": {
"color": 3,
"width": 236,
"height": 488,
"content": "# 📑 STEP 5: Line Item Processing\n\n**Purpose**: Split line items for individual spreadsheet rows\n\n**Process**:\n- 📋 Extract Line Items array from parsed data\n- 🔄 Create separate execution for each line item\n- 📊 Enables detailed item-level tracking\n\n**Output**: Individual line items for Google Sheets"
},
"typeVersion": 1
},
{
"id": "09ea2e0e-3455-4a4f-b104-caf7e145ed59",
"name": "📊 시트 저장 안내",
"type": "n8n-nodes-base.stickyNote",
"position": [
-32,
1392
],
"parameters": {
"color": 3,
"width": 268,
"height": 488,
"content": "# 📊 STEP 6: Save to Spreadsheet\n\n**Purpose**: Store extracted invoice data in Google Sheets\n\n**Mapping**:\n- 🏢 Vendor Name → Header data\n- 🔢 Invoice Number → Header data\n- 📅 Dates → Header data\n- 💰 Amounts → Header data\n- 📋 Line Items → Individual rows\n\n**Sheet**: Test Invoice Records\n**Format**: USER_ENTERED (preserves formatting)"
},
"typeVersion": 1
},
{
"id": "7696a262-8c9c-4f0a-89ba-0998fef40fcb",
"name": "🔗 병합 안내",
"type": "n8n-nodes-base.stickyNote",
"position": [
256,
1392
],
"parameters": {
"color": 3,
"width": 218,
"height": 486,
"content": "# 🔗 STEP 7: Data Merge\n\n**Purpose**: Combine file metadata with processed data\n\n**Inputs**:\n- 📁 File information from Google Drive\n- 📊 Processed invoice data from sheets\n\n**Output**: Combined data for file renaming"
},
"typeVersion": 1
},
{
"id": "f6db208f-ead8-4762-afde-d82c511344e8",
"name": "📝 이름 변경 안내",
"type": "n8n-nodes-base.stickyNote",
"position": [
496,
1392
],
"parameters": {
"color": 3,
"width": 202,
"height": 486,
"content": "# 📝 STEP 8: File Renaming\n\n**Purpose**: Rename file with vendor and invoice number\n\n**Format**: \"{Vendor Name} - {Invoice Number}\"\n\n**Example**: \"Acme Corp - INV-2024-001\"\n\n**Error Handling**: Continues even if renaming fails"
},
"typeVersion": 1
},
{
"id": "c23af4ed-ad50-4992-8bd2-fb884121e17c",
"name": "✅ 확인 안내",
"type": "n8n-nodes-base.stickyNote",
"position": [
720,
1392
],
"parameters": {
"color": 3,
"width": 250,
"height": 486,
"content": "# ✅ STEP 9: Confirmation\n\n**Purpose**: Send success message to user\n\n**Message**: Confirms invoice processing completion\n\n**Includes**: Reference to check Google Sheet\n\n**User Experience**: Clear feedback on completion"
},
"typeVersion": 1
},
{
"id": "619818b5-2e30-46ef-a1fe-c9653e9fe662",
"name": "🧾 경비 처리 문서화",
"type": "n8n-nodes-base.stickyNote",
"position": [
-2224,
-448
],
"parameters": {
"color": 5,
"width": 772,
"height": 1232,
"content": "# 🧾 EXPENSE PROCESSING SECTION\n\n## 🎯 Purpose\nThis section monitors a Google Drive folder for new expense receipts. Donna, the AI Accountant, extracts expense data and automatically categorizes it using AI.\n\n## 🔄 Process Flow\n1. **📁 Drive Monitor**: Watches \"Expense Receipts\" folder every minute\n2. **📥 File Download**: Downloads new PDF files\n3. **🤖 AI Processing**: Google Gemini extracts expense data\n4. **🏷️ AI Categorization**: OpenRouter LLM categorizes expenses\n5. **📊 Data Storage**: Information saved to \"Expenses Recording\" spreadsheet\n6. **✅ Completion**: Process confirmation\n\n## 📋 Extracted Fields\n- Merchant Name\n- Transaction Date\n- Total Amount\n- Tax Amount\n- Payment Method\n- Line Items (if available)\n- AI-Generated Category\n\n## 🏷️ Expense Categories (17 Total)\n- 📦 Cost of Goods Sold\n- 📢 Advertising & Marketing\n- 💰 Payroll & Wages\n- 🎯 Employee Benefits\n- 🤝 Contract Labor\n- 🏢 Rent & Leases\n- ⚡ Utilities\n- 📎 Office Supplies & G&A\n- 💻 Software & Cloud Subscriptions\n- ✈️ Travel Meals & Entertainment\n- 👔 Professional Services\n- 🛡️ Insurance\n- 🔧 Repairs & Maintenance\n- 🏛️ Taxes & Licenses\n- 💳 Interest Expense\n- 📉 Depreciation & Amortization\n- 📋 Other Miscellaneous\n\n## ⚙️ Configuration Notes\n- Monitors folder every minute for new files\n- Processes PDF files automatically\n- AI categorization uses structured output parsing\n- Error handling continues processing other files"
},
"typeVersion": 1
},
{
"id": "be419798-2cc6-4819-9a1d-59201efe77c3",
"name": "📁 경비 트리거 안내",
"type": "n8n-nodes-base.stickyNote",
"position": [
640,
176
],
"parameters": {
"color": 4,
"width": 492,
"height": 296,
"content": "# 📁 EXPENSE TRIGGER\n\n**Purpose**: Monitor Google Drive folder for new expense receipts\n\n**Configuration**:\n- 📂 Folder: \"Expense Receipts\"\n- ⏰ Frequency: Every minute\n- 🚨 Event: File created\n- 📄 File Types: All (but processes PDF)\n\n**Output**: File metadata for new uploads"
},
"typeVersion": 1
},
{
"id": "791fb721-f346-42d8-9628-1d5b2db5ab24",
"name": "🏷️ 분류 안내",
"type": "n8n-nodes-base.stickyNote",
"position": [
640,
-144
],
"parameters": {
"color": 4,
"width": 492,
"height": 296,
"content": "# 🏷️ AI CATEGORIZATION\n\n**Purpose**: Automatically categorize expenses using AI\n\n**Process**:\n- 🤖 Uses OpenRouter LLM\n- 📋 17 predefined categories\n- 🎯 Structured JSON output\n- 🧠 Context-aware classification\n\n**Output**: Category assignment for expense"
},
"typeVersion": 1
},
{
"id": "39b5e552-93b9-437b-b2ce-2ca403a7cd8a",
"name": "🏦 은행 명세서 처리 문서화",
"type": "n8n-nodes-base.stickyNote",
"position": [
-2224,
-1328
],
"parameters": {
"color": 5,
"width": 772,
"height": 856,
"content": "# 🏦 BANK STATEMENT PROCESSING SECTION\n\n## 🎯 Purpose\nThis section monitors a Google Drive folder for new bank statements. Victor, the AI Controller, extracts transaction data for reconciliation and analysis.\n\n## 🔄 Process Flow\n1. **📁 Drive Monitor**: Watches \"Bank Statements\" folder every minute\n2. **📥 File Download**: Downloads new PDF bank statements\n3. **🤖 AI Processing**: Google Gemini extracts transaction data\n4. **🔄 Data Parsing**: Custom code handles multiple transactions\n5. **📊 Data Storage**: Information saved to \"Bank Transactions Record\" spreadsheet\n6. **✅ Completion**: Process confirmation\n\n## 📋 Extracted Fields\n- Transaction ID\n- Date\n- Description / Payee\n- Debit (-)\n- Credit (+)\n- Currency\n- Running Balance\n- Notes / Category (optional)\n\n## ⚙️ Configuration Notes\n- Monitors folder every minute for new files\n- Processes PDF bank statements automatically\n- Custom JavaScript code handles transaction arrays\n- Error handling continues processing other files\n- Supports multiple transaction formats"
},
"typeVersion": 1
},
{
"id": "cba011da-354b-4c58-9942-f6f5fb6b4135",
"name": "Victor - 컨트롤러",
"type": "n8n-nodes-base.stickyNote",
"position": [
-1344,
-1136
],
"parameters": {
"color": 6,
"width": 324,
"height": 512,
"content": "# Victor - Controller 👨💼\n\n**Role**: Bank Statement Processing & Transaction Reconciliation\n\n**Responsibilities**:\n- ✅ Extract transaction details\n- ✅ Process multiple transactions per statement\n- ✅ Maintain running balances\n- ✅ Handle various bank formats\n\n**AI Capabilities**:\n- 🧠 Multi-transaction extraction\n- 📊 Balance reconciliation\n- 🔄 Format standardization"
},
"typeVersion": 1
},
{
"id": "c3b83adc-d38c-4b18-ae37-a5e801c7b4d5",
"name": "🔄 은행 파서 안내",
"type": "n8n-nodes-base.stickyNote",
"position": [
1168,
-1136
],
"parameters": {
"color": 4,
"width": 348,
"height": 504,
"content": "# 🔄 CUSTOM TRANSACTION PARSER\n\n**Purpose**: Parse multiple bank transactions from AI response\n\n**Features**:\n- 🧹 Cleans JSON formatting\n- 📊 Handles multiple response formats\n- 🔄 Converts to n8n array format\n- ⚠️ Comprehensive error handling\n\n**Output**: Individual transaction objects"
},
"typeVersion": 1
},
{
"id": "173fbf7e-f00e-4ab8-a1b9-a63aacb17648",
"name": "📈 재무 분석 문서화",
"type": "n8n-nodes-base.stickyNote",
"position": [
-2224,
-2480
],
"parameters": {
"color": 5,
"width": 756,
"height": 1104,
"content": "# 📈 FINANCIAL ANALYSIS AGENT SECTION\n\n## 🎯 Purpose\nAndrew, the AI CFO, provides intelligent financial analysis and reporting. He can access all three financial spreadsheets and answer complex queries using natural language.\n\n## 🔄 Process Flow\n1. **▶️ Manual Trigger**: Execute when financial analysis is needed\n2. **🤖 AI Agent**: Uses advanced LLM for data analysis\n3. **📊 Data Access**: Connects to all three Google Sheets\n4. **💬 Natural Language**: Processes queries in plain English\n5. **📈 Analysis**: Generates insights and reports\n6. **📋 Response**: Formatted results and recommendations\n\n## 🗃️ Data Access\n- **📄 Invoices**: Client billing and payment tracking\n- **🧾 Expenses**: Categorized expense analysis\n- **🏦 Transactions**: Bank account reconciliation\n\n## 💡 Query Examples\n- \"What are the last 10 bank transactions?\"\n- \"What is the total value of invoices for December 2023?\"\n- \"List all unpaid invoices sorted by amount\"\n- \"What was our highest expense category last month?\"\n- \"Show me transactions over $1000 in the past week\"\n- \"Calculate the average invoice amount by client\"\n- \"Compare Q3 vs Q4 expenses by category\"\n- \"Generate a cash flow summary for the last quarter\"\n\n## 🤖 AI Capabilities\n- **📊 Data Analysis**: Complex calculations and aggregations\n- **📈 Trend Analysis**: Identify patterns and insights\n- **📋 Report Generation**: Structured financial reports\n- **💬 Natural Language**: No SQL or technical knowledge required\n- **🔍 Data Mining**: Find specific transactions or patterns\n\n## ⚙️ Configuration Notes\n- Uses GPT-4.1 via OpenRouter for advanced reasoning\n- Connected to all three financial spreadsheets as tools\n- Disabled by default - enable when analysis is needed\n- Maintains data confidentiality and security"
},
"typeVersion": 1
},
{
"id": "3bca707d-5591-48aa-9d2b-463f3d116b87",
"name": "Andrew - CFO",
"type": "n8n-nodes-base.stickyNote",
"position": [
-1328,
-2160
],
"parameters": {
"color": 6,
"width": 308,
"height": 512,
"content": "# Andrew - CFO 👨💼\n\n**Role**: Financial Analysis & Strategic Reporting\n\n**Responsibilities**:\n- ✅ Generate financial insights\n- ✅ Answer complex queries\n- ✅ Create executive reports\n- ✅ Provide strategic recommendations\n\n**AI Capabilities**:\n- 🧠 Advanced data analysis\n- 📊 Multi-source data synthesis\n- 💬 Natural language processing\n- 📈 Trend identification"
},
"typeVersion": 1
},
{
"id": "c12b117e-e2f7-4c01-895a-5d30f1b1d973",
"name": "📊 분석 트리거 안내",
"type": "n8n-nodes-base.stickyNote",
"position": [
288,
-2160
],
"parameters": {
"color": 4,
"width": 300,
"height": 518,
"content": "# 📊 ANALYSIS TRIGGER\n\n**Purpose**: Manual trigger for financial analysis queries\n\n**Usage**:\n- 🔘 Enable this trigger when analysis is needed\n- 💬 Send financial queries to the AI agent\n- 📈 Get insights from all your financial data\n\n**Note**: Disabled by default for security"
},
"typeVersion": 1
},
{
"id": "47cd562d-1c49-46c4-94ab-ce6bd0f2a2de",
"name": "🗃️ 데이터 도구 안내",
"type": "n8n-nodes-base.stickyNote",
"position": [
624,
-2160
],
"parameters": {
"color": 4,
"width": 302,
"height": 520,
"content": "# 🗃️ DATA ACCESS TOOLS\n\n**Purpose**: Connect AI agent to financial spreadsheets\n\n**Tools Available**:\n- 📄 **Invoices Tool**: Invoice records and billing data\n- 🧾 **Expenses Tool**: Categorized expense tracking\n- 🏦 **Transactions Tool**: Bank transaction history\n\n**Features**:\n- 🔍 Auto-detect data ranges\n- 📊 Full spreadsheet access\n- 🔐 Secure authentication\n- 📈 Real-time data access"
},
"typeVersion": 1
},
{
"id": "e2d55436-ebd7-48a8-9b99-02c04444afad",
"name": "Donna - 회계사",
"type": "n8n-nodes-base.stickyNote",
"position": [
-1344,
-144
],
"parameters": {
"color": 6,
"width": 324,
"height": 608,
"content": "# Donna - Accountant 👩💼\n\n**Role**: Expense Processing & Categorization Specialist\n\n**Responsibilities**:\n- ✅ Extract merchant & transaction details\n- ✅ Categorize expenses automatically\n- ✅ Process receipt line items\n- ✅ Ensure compliance categorization\n\n**AI Capabilities**:\n- 🧠 Smart expense categorization\n- 📋 Receipt data extraction\n- 🏷️ 17-category classification system"
},
"typeVersion": 1
},
{
"id": "40503797-869e-46ec-ad59-83f94f78d757",
"name": "스티커 노트13",
"type": "n8n-nodes-base.stickyNote",
"position": [
-1376,
800
],
"parameters": {
"color": 7,
"width": 2416,
"height": 1152,
"content": ""
},
"typeVersion": 1
},
{
"id": "e3db55b4-86fe-44f8-9bf8-3e97f5db942f",
"name": "스티커 노트14",
"type": "n8n-nodes-base.stickyNote",
"position": [
-1376,
-176
],
"parameters": {
"color": 7,
"width": 2544,
"height": 688,
"content": ""
},
"typeVersion": 1
},
{
"id": "c3f4650a-f442-417d-b446-af32cb3bfeca",
"name": "스티커 노트15",
"type": "n8n-nodes-base.stickyNote",
"position": [
-1376,
-1168
],
"parameters": {
"color": 7,
"width": 2928,
"height": 576,
"content": ""
},
"typeVersion": 1
},
{
"id": "5720a9c7-16ec-412b-80ed-a32c70eeb9f6",
"name": "스티커 노트16",
"type": "n8n-nodes-base.stickyNote",
"position": [
-1376,
-2208
],
"parameters": {
"color": 7,
"width": 2352,
"height": 608,
"content": ""
},
"typeVersion": 1
},
{
"id": "423bea12-2767-48d3-844b-26815d45960a",
"name": "스티커 노트26",
"type": "n8n-nodes-base.stickyNote",
"position": [
-3520,
80
],
"parameters": {
"color": 7,
"width": 848,
"height": 848,
"content": ""
},
"typeVersion": 1
},
{
"id": "904576db-3e5a-4b7d-bb64-0f181163ed51",
"name": "스티커 노트27",
"type": "n8n-nodes-base.stickyNote",
"position": [
-1936,
-3376
],
"parameters": {
"color": 7,
"width": 1312,
"height": 784,
"content": ""
},
"typeVersion": 1
},
{
"id": "4b28450e-ede0-4ac3-8120-19c5dea201ab",
"name": "스티커 노트8",
"type": "n8n-nodes-base.stickyNote",
"position": [
-1552,
-3504
],
"parameters": {
"width": 544,
"height": 80,
"content": "# Virtual Accounting Department"
},
"typeVersion": 1
}
],
"pinData": {},
"connections": {
"347e16d9-febc-4f44-8539-112ca95e3df5": {
"main": [
[
{
"node": "6d94b80f-914f-4c60-b0b8-1fec176ba707",
"type": "main",
"index": 0
}
]
]
},
"60c60b57-a29c-4b84-a364-7ff194338a23": {
"main": [
[
{
"node": "67e50b05-8095-4733-b14d-aac6181163aa",
"type": "main",
"index": 0
}
]
]
},
"1cbde03d-4562-4b08-9001-e3e13bc7cf9b": {
"main": [
[
{
"node": "bf1db04b-5b67-4334-ab21-1e6e4d40fa6a",
"type": "main",
"index": 0
}
]
]
},
"39e1c9dd-e85d-4548-8c62-24209f4b8fc0": {
"ai_tool": [
[
{
"node": "1cbde03d-4562-4b08-9001-e3e13bc7cf9b",
"type": "ai_tool",
"index": 0
}
]
]
},
"8fea6832-8064-46d3-a71e-eb42b325e58b": {
"ai_tool": [
[
{
"node": "1cbde03d-4562-4b08-9001-e3e13bc7cf9b",
"type": "ai_tool",
"index": 0
}
]
]
},
"ce9ddc97-8776-4805-9299-e8898ccd4cdc": {
"main": [
[
{
"node": "2951c2d7-f543-4ea7-acdb-67b9fa9c8d31",
"type": "main",
"index": 0
}
]
]
},
"2951c2d7-f543-4ea7-acdb-67b9fa9c8d31": {
"main": [
[
{
"node": "60c60b57-a29c-4b84-a364-7ff194338a23",
"type": "main",
"index": 1
}
]
]
},
"947a8138-e565-4738-b1c8-8b85068ba6e4": {
"main": [
[
{
"node": "5ebbafe9-d67e-4e86-be8c-e02c79f177d4",
"type": "main",
"index": 0
}
]
]
},
"82edfbf5-53d1-4105-ae08-85fdd4d4a5de": {
"main": [
[
{
"node": "ce9ddc97-8776-4805-9299-e8898ccd4cdc",
"type": "main",
"index": 0
}
]
]
},
"dbe2be8e-98f0-4c74-81ef-b69d80e7759d": {
"main": [
[
{
"node": "32e2ac3c-d6eb-404b-99df-0ed49d18b3fe",
"type": "main",
"index": 0
}
]
]
},
"df7a4279-7e74-4faf-8d5a-b87a657ce9d2": {
"main": [
[
{
"node": "947a8138-e565-4738-b1c8-8b85068ba6e4",
"type": "main",
"index": 0
}
]
]
},
"08e9f03b-c1b5-4d53-8d63-5be9c1f57187": {
"main": [
[
{
"node": "60c60b57-a29c-4b84-a364-7ff194338a23",
"type": "main",
"index": 0
}
]
]
},
"df86bfde-6554-4bfd-8cfe-3cc2cfc6d4f8": {
"ai_tool": [
[
{
"node": "1cbde03d-4562-4b08-9001-e3e13bc7cf9b",
"type": "ai_tool",
"index": 0
}
]
]
},
"55f393cc-9c47-42db-8803-f1e090459605": {
"main": [
[
{
"node": "529732d1-eee3-471d-80b7-0ac6320ed6d2",
"type": "main",
"index": 0
}
]
]
},
"0f89afbd-3b0b-48a6-b92d-838655f3424e": {
"main": [
[
{
"node": "03bc404a-d364-42b4-900f-ca61e4dd9b67",
"type": "main",
"index": 0
}
]
]
},
"6d94b80f-914f-4c60-b0b8-1fec176ba707": {
"main": [
[
{
"node": "4b5d634e-53f9-41d5-938c-7cf6efe61411",
"type": "main",
"index": 0
}
]
]
},
"5ebbafe9-d67e-4e86-be8c-e02c79f177d4": {
"main": [
[
{
"node": "0f89afbd-3b0b-48a6-b92d-838655f3424e",
"type": "main",
"index": 0
}
]
]
},
"67e50b05-8095-4733-b14d-aac6181163aa": {
"main": [
[
{
"node": "25cc249b-c780-4a34-8cbb-b2aa8a8adf54",
"type": "main",
"index": 0
}
]
]
},
"c638cf56-555c-489d-bb83-bf385ae88af4": {
"main": [
[
{
"node": "dbe2be8e-98f0-4c74-81ef-b69d80e7759d",
"type": "main",
"index": 0
}
]
]
},
"f8c79b50-6d77-45f1-b7df-4b48a992402d": {
"main": [
[
{
"node": "55f393cc-9c47-42db-8803-f1e090459605",
"type": "main",
"index": 0
}
]
]
},
"f1a9203a-0d21-46f0-aa9a-afff675427dc": {
"ai_languageModel": [
[
{
"node": "5ebbafe9-d67e-4e86-be8c-e02c79f177d4",
"type": "ai_languageModel",
"index": 0
}
]
]
},
"a0d38cbe-d401-458d-afde-7b46172f1b9a": {
"ai_languageModel": [
[
{
"node": "1cbde03d-4562-4b08-9001-e3e13bc7cf9b",
"type": "ai_languageModel",
"index": 0
}
]
]
},
"9638204f-cb80-4fb5-a146-055160fd1437": {
"ai_outputParser": [
[
{
"node": "5ebbafe9-d67e-4e86-be8c-e02c79f177d4",
"type": "ai_outputParser",
"index": 0
}
]
]
},
"ec55993a-2652-4e2d-9e25-3e507f93c487": {
"main": [
[
{
"node": "b5293bee-dadb-4de1-9142-4efaf432d90f",
"type": "main",
"index": 0
},
{
"node": "08e9f03b-c1b5-4d53-8d63-5be9c1f57187",
"type": "main",
"index": 0
}
]
]
},
"b5293bee-dadb-4de1-9142-4efaf432d90f": {
"main": [
[
{
"node": "3679bcea-f0aa-4c4e-82b0-43c147564377",
"type": "main",
"index": 0
}
]
]
},
"32e2ac3c-d6eb-404b-99df-0ed49d18b3fe": {
"main": [
[
{
"node": "2a020ce2-5406-410f-8530-42c8abdc2128",
"type": "main",
"index": 0
}
]
]
},
"529732d1-eee3-471d-80b7-0ac6320ed6d2": {
"main": [
[
{
"node": "1765ea24-57c2-4c5f-9ca0-70338934195d",
"type": "main",
"index": 0
}
]
]
},
"3679bcea-f0aa-4c4e-82b0-43c147564377": {
"main": [
[
{
"node": "82edfbf5-53d1-4105-ae08-85fdd4d4a5de",
"type": "main",
"index": 0
}
],
[
{
"node": "b5293bee-dadb-4de1-9142-4efaf432d90f",
"type": "main",
"index": 0
}
]
]
},
"2a020ce2-5406-410f-8530-42c8abdc2128": {
"main": [
[
{
"node": "df7a4279-7e74-4faf-8d5a-b87a657ce9d2",
"type": "main",
"index": 0
}
],
[
{
"node": "32e2ac3c-d6eb-404b-99df-0ed49d18b3fe",
"type": "main",
"index": 0
}
]
]
},
"1765ea24-57c2-4c5f-9ca0-70338934195d": {
"main": [
[
{
"node": "347e16d9-febc-4f44-8539-112ca95e3df5",
"type": "main",
"index": 0
}
],
[
{
"node": "529732d1-eee3-471d-80b7-0ac6320ed6d2",
"type": "main",
"index": 0
}
]
]
},
"d96a6fe2-fe52-4bdc-8199-7c5de0e18d03": {
"main": [
[
{
"node": "1cbde03d-4562-4b08-9001-e3e13bc7cf9b",
"type": "main",
"index": 0
}
]
]
}
}
}자주 묻는 질문
이 워크플로우를 어떻게 사용하나요?
위의 JSON 구성 코드를 복사하여 n8n 인스턴스에서 새 워크플로우를 생성하고 "JSON에서 가져오기"를 선택한 후, 구성을 붙여넣고 필요에 따라 인증 설정을 수정하세요.
이 워크플로우는 어떤 시나리오에 적합한가요?
고급 - 콘텐츠 제작, 멀티모달 AI
유료인가요?
이 워크플로우는 완전히 무료이며 직접 가져와 사용할 수 있습니다. 다만, 워크플로우에서 사용하는 타사 서비스(예: OpenAI API)는 사용자 직접 비용을 지불해야 할 수 있습니다.
관련 워크플로우 추천
WordPress 블로그 자동화 프로페셔널 에디션(심층 연구) v2.1 마켓
GPT-4o, Perplexity AI 및 다국어 지원을 사용한 SEO 최적화 블로그 생성 자동화
If
Set
Xml
+
If
Set
Xml
125 노드Daniel Ng
콘텐츠 제작
OpenAI, RunwayML, ElevenLabs를 사용한 무면식 숏폼 비디오 자동화
OpenAI, RunwayML, ElevenLabs를 사용한 무면쇼트 비디오 자동화: 스크립트부터 소셜 미디어까지
Set
Code
Wait
+
Set
Code
Wait
56 노드LeeWei
콘텐츠 제작
1. 플레이리스트 상세 설정 로봇 복사본
Suno, GPT-4, Runway, Creatomate로 AI 생성 YouTube 음악 플레이리스트 생성
If
Set
Code
+
If
Set
Code
203 노드Joseph
콘텐츠 제작
합성
Suno API, Claude, Telegram 로봇을 통해 완전한 20곡 YouTube 플레이리스트 생성
If
Set
Code
+
If
Set
Code
150 노드Joseph
콘텐츠 제작
시각화 참조 라이브러리에서 n8n 노드를 탐색
可视化 참조 라이브러리에서 n8n 노드를 탐색
If
Ftp
Set
+
If
Ftp
Set
113 노드I versus AI
기타
컨텍스트 혼합 RAG AI 콘텐츠
Google Drive에서 Supabase 상황 벡터 데이터베이스로 동기화, RAG 애플리케이션 사용
If
Set
Code
+
If
Set
Code
76 노드Michael Taleb
AI RAG
워크플로우 정보
난이도
고급
노드 수76
카테고리2
노드 유형16
저자
Didac Fernandez
@didac-fgPro VibeCoder & Master Jedi in Business Applied GenAI | Expert in Process Automation and AI Business Transformation | IT & Cyber
외부 링크
n8n.io에서 보기 →
이 워크플로우 공유
